Semi Electric Pallet Stacker
Semi Electric Pallet Stacker
Semi Electric Stacker with Adjustable Base Legs. Single Mast with a Lift Height of 63”.
Forks adjust from side to side to accommodate skid widths. Adjustable forks lower to the minimum height 2 1/8”. Overall fork width 8 1/4” to 28 1/2” (Adjustable). Straddle Legs adjust to three positions. Sturdy mast made of rolled U- shapes. Powerful lift motor 2.1 HP. Battery Gauge and On/Off Switch. Integrated 150 Ah maintenance free battery provides more than enough power to handle heavy duty lifting. Integrated Charger facilitates easy and reliable charging.
Pricing
| Semi Electric - Stacker | ||||||
|---|---|---|---|---|---|---|
| Model Number | Fork Size [WxL] | Lift height Max | Overall Size [WxL] | Capacity (lbs.) | Weight (lbs.) | Price |
| DS-BALLYPAL22AG63 | 4" x 42” | 63" | 46” to 58” x 66 1/2” | 2,200 | 830 | $ |
| All dimensions are in inches | ||||||
Note: All products should be inspected frequently to insure safe operation. Final testing and inspection left to end user after final assembly has been completed.
Features
Standard Features
Capacity 2200 lbs.
Lift Height Max. 63”
Lift Height Min. 2 1/8”
Fork Length 42”
Fork Width 4”
Base Legs (OD) 46” to 58”
Overall Length 66 1/2”
Overall Width 46” to 58”
Overall Height 80”
Single Mast
Weight 830 lbs.
1 Battery 12V/150Ah
Options
No options available for this product
Parts
Please call 1-888-802-3651 for replacement parts
Documentation / Videos
No documentation or videos available for this product.
