Brandon Omni Mini Crane
Brandon Omni Mini Crane
The Brandon OMNI telehandler has multi-directional steering allowing the user to maintain its orientation while maneuvering in different directions.
It affords the user exceptional control during operation. Like its counterpart, the Brandon 6, the OMNI can be equipped with multiple attachments.
Standard Features:
24 Feet (7.33M) of Vertical Reach
28 Feet (8.5M) of Vertical Reach
18 Feet (5.49M) of Horizontal Reach
4000 LB (2500 Kg) Capacity
Woods Power Grip system
5800 LB (2500 Kg) Machine Weight
2 Wheel Drive, 2 Wheel Brakes
36 Volt Battery Powered
Made in the USA
Specifications:
Model: Brandon Omni
Capacity: 4,000 lbs
Power: 36Volt 7HP Electric Motor
Steering: 2 Omni Directional Wheels
Drive: 2 Wheel Drive and Braking
Charger: On-board 110V
Weight: 5,800 Lbs + Attachment
Boom: Base unit, 2 telescoping booms and one manual pull-out boom. Attachments replace pull-out boom.
Rated Load Limiter: Displays rated load and actual load. Stops when overload is reached. Detects attachment and adjusts load parameters.
System Display: Includes Rated Load Limiter and system information
Note: All products should be inspected frequently to insure safe operation. Final testing and inspection left to end user after final assembly has been completed.
CALL US AT (888)-802-3651 OR CLICK BUTTON FOR A FREIGHT QUOTE
WHEN YOU PURCHASE A TELEHANDLER FROM DIVERSE SUPPLY, YOU ARE SIMULTANEOUSLY AGREEING THAT DIVERSE SUPPLY IS NOT LIABLE FOR ANY INJURY OR PROPERTY DAMAGE RELATED TO THE USE OF THE TELEHANDLER.
| Model Number | Weight Capacity [Lbs] |
Power | Price |
|---|---|---|---|
| DS-OMNI BT28-0 | 4,000 | 36Volt 7HP Electric Motor | $178,700 |
***PRICES SUBJECT TO CHANGE WITHOUT NOTICE***
| Model Number | Description | Capacity [lbs] |
Price |
|---|---|---|---|
| DS-TPTA | Powered Tip Assembly* | n/a | $8,594 |
| DS-TRO | Robot Lifter[Includes 3 Axis Manipulator] | 1,000 | $19,465 |
| DS-TGL | Glass Lifter w/side Shift [Includes 3 Axis Manipulator] | 1,100 | $28,532 |
| DS-FK* | Forks [requires powered tip assembly] | 1,500 | $3,456 |
| DS-MB* | Man Basket [requires powered tip assembly] | 500 | $6,375 |
| DS-WN | Winch 90' of cable | 3,000 | $13,125 |
| DS-WN-1995 | Winch 230' of cable | 3,000 | $13,525 |
| DS-3708 | Hook Brandon 6 - 4th stage pull-out boom | 5,000 | $2,200 |
| DS-JB | Jib [requires powered tip assembly] | 1,000 | $1,156 |
SO 9001 REGISTERED MANUFACTURING COMPANY
***PRICES SUBJECT TO CHANGE WITHOUT NOTICE***
